HiWay-5S – Powerful Signal Booster for Vehicles, Yachts, and Mobile Spaces
The HiWay-5S is one of the most advanced mobile signal boosters ever built, designed to significantly enhance voice and data coverage for all UK and European networks. It supports five key frequency bands: 800, 900, 1800, 2100, and 2600 MHz making it ideal for use in moving or stationary vehicles, yachts at sea, mobile homes, caravans, and cabins.
Thanks to its wide coverage range, the HiWay-5S improves signal strength in indoor areas up to 500 square meters (open space). It delivers a superior communication experience, offering clearer voice calls and faster mobile data speeds. Within just one minute of being powered on, the booster automatically adjusts itself for optimal signal performance.
For added flexibility, you can easily convert the HiWay-5S into a home or office booster by adding a few extra accessories, making it a versatile solution for various connectivity needs.
Key Features
- Supports Multiple Networks: EGSM900, LTE800, DCS/LTE1800, WCDMA2100, LTE2600 MHz
- Coverage Area: Up to 500 sqm (open indoor space)
- User Capacity: Handles 15–25 simultaneous users
- Fast Auto Adjustment: Optimizes signal performance within 1 minute
- Complete Kit: Includes outdoor directional antenna and coaxial cable
- Smart Display: LCD shows real-time signal strength, gain, and status
- Advanced Control: Features AGC (Automatic Gain Control) and MGC (Manual  Gain Control)
- Certified Quality: CE and RoHS certified for safety and compliance
- Reliable Warranty: 3-Year Warranty and 15-Day Money-Back Guarantee
Whether you’re traveling across the country or anchored offshore, the HiWay-5S ensures you stay connected. Its durable design, intelligent features, and powerful performance make it the perfect companion for life on the move.
Certifications
All our Boosters are certified under the UK and EU safety Laws
PRODUCTS SPECIFCATIONS
| Coverage Area | 500 m² |
| Application | Home and Office Building |
| Network Type | Calls, 3G / UMTS, 4G / LTE |
| Frequency | 800 MHz (4G/LTE), 900 MHz (GSM/EGSM), 1800 MHz (DCS/LTE), 2100 MHz (3G/WCDMA), 2600 MHz (4G/LTE) |
| Frequency Range | 832~862MHz (Uplink) 791~821MHz (Downlink), 880~915MHz (Uplink) 925~960MHz (Downlink), 1710~1785MHz (Uplink) 1805~1880MHz (Downlink), 1920~1980MHz (Uplink) 2110~2170MHz (Downlink), 2500~2570MHz (Uplink) 2620~2690MHz (Downlink) |
| Number Of Bands | Five Band |
| Max. Gain | 55dB (Uplink) – 60dB (Downlink) |
| MGC (Step Attenuation) | ≥ 16dB / 1 dB step, dip switch control |
| Intelligent AGC (ALC / ISO) | ≥42 dB / ≥42 dB |
| Gain Flatness | Typical ≤5 dB (P-P) |
| Noise Figure @ Max. System Gain | Typical ≤5 dB |
| V.S.W.R | Typical ≤2 |
| Group Delay | ≤ 1 μs |
| Frequency Stability | ≤0.01 ppm |
| Power Supply | Input AC100~240V.50/60Hz, Output DC12V/7A |
| Power Consumption | ≤24W |
| Input & Output Impedance | 50 ohm |
| LCD Display | Frequency, Gain, Output Power, ALC, ISO, etc. |
| Indication LEDs | No |
| I /O Port Type | N-Female |
| Dimensions | 153 x 246 x 36mm/ 6 x 9.7 x 1.4inch |
| Booster Weight | 1.8 kg |
| Booster Weight with KIT | 5 kg |
| Operating Temperature | -10ºC~+55ºC |
| Storage Temperature | -10ºC~+80ºC |
| Relative Humidity | 5% – 95% |
| Barometric Pressure | 55 kPa -106 kPa |
| Environment Conditions | IP40 |
